General Information - TR60 Off-Highway Truck
BODY
Longitudinal 'V' type floor with integral transverse box-
section stiffeners. The body is exhaust heated and rests on
resilient impact absorption pads.
Body wear surfaces are high hardness (360-440 BHN)
abrasion resistant steel. Yield strength of plates 1 000 MPa
(145 000 lbf/in²).
Plate Thicknesses:
Floor ......................................................... 19 mm (0.75 in)
Side .......................................................... 10 mm (0.39 in)
Front, lower............................................... 10 mm (0.39 in)
ROPS Cabguard SAE J1040 Feb 86. ISO 3471
Volumes:
Struck (SAE) ............................................... 26 m³ (34 yd³)
Heaped 2:1 (SAE) ...................................... 35 m³ (46 yd³)
SERVICE CAPACITIES
Engine Crankcase and Filters............ 66 litres (17.5 US gal)
Transmission and Filters.................... 85 litres (22.5 US gal)
Cooling System ................................ 157 litres (41.5 US gal)
Fuel Tank .......................................... 606 litres (160 US gal)
Steering Hydraulic Tank ....................... 61 litres (16 US gal)
Steering System.................................... 72 litres (19 US gal)
Body and Brake Cooling Tank ............ 216 litres (57 US gal)
Body and Brake Cooling System ........ 258 litres (68 US gal)
Planetaries (Total) ............................. 43 litres (11.4 US gal)
Differential .......................................... 52 litres (13.7 US gal)
Front Ride Strut (Each) ........................ 14 litres (3.7 US gal)
Rear Ride Strut (Each)......................... 17 litres (4.5 US gal)
Power Takeoff ........................................... 4 litres (1 US gal)
Typical Noise Levels
Operator Ear (ISO 6394)............................................ 79 dbA
*Exterior Sound Rating (SAE J88 JUN 86) ................ 89 dbA
* - The above result is for the mode giving the highest
exterior sound level when measured and operated as per
the prescribed procedures of the standard. Results shown
are for the vehicle in base configuration.
Note: Noise Level Exposure to the operator and bystander
personnel may be higher depending upon proximity to
buildings, rock piles, machinery etc.. The actual job site
Noise Level Exposure must be measured and applicable
regulations complied with in respect to Employee Hearing
Protection.
* * * *
Vehicle Weights (Mass)
kg lb
Chassis, with hoists 30 600 67 460
Body, standard 10 650 23 480
Net Weight 41 250 90 940
PAYLOAD, maximum 54 430 120 000
Maximum Gross Weight* 95 680 210 940
FOR UNIT EQIPPED WITH OPTIONAL HARD ROCK
BODY:
Chassis, with hoists 30 600 67 460
Body, with wear plates 13 200 29 100
Net Weight 43 800 96 560
PAYLOAD, maximum 51 880 114 380
Maximum Gross Weight* 95 680 210 940
* Maximum permissable gross vehicle weight with options,
attachments, full tank and payload.
WEIGHT DISTRIBUTION Front Axle Rear Axle
Empty % 48 52
Loaded % 34 66
