Terex TR60 - Page 25

Section 100-0010
5
SM 1904 1-00
Chassis - Chassis, Hood and Fenders
1 - Radiator Guard
2 - Cover Plate
3 - Washer
4 - Bolt
5 - Bolt
6 - Nut
7 - Bolt
8 - Grille
9 - Bolt
Fig. 5 - Radiator Guard and Mounting
* * * *
SM - 2398
10 - Bracket
11 - Hardened Washer
12 - Nut
13 - Bracket
8
11
11
11
11
11
11
7
7
6
10
5
9
12
7
13
1
2
3
4
