4
Section 110-0130
Engine - Power Takeoff
SM 1573 Rev 1 1-00
MAINTENANCE
Numbers in parentheses refer to Fig. 1.
Note: Refer to Section 300-0020, LUBRICATION
SYSTEM for recommended check and drain intervals
and lubricant specifications.
Oil Level Check
Remove oil level plug (6) from the front of PTO cover
(6) and, if oil level is below the bottom of the filler
hole, add lubricant until it flows from the filler hole.
Reinstall oil level plug (6) and tighten securely.
Drain and Refill
To drain: Remove drain plug (6) from flywheel cover
case (1) and drain oil into a suitable container.
Reinstall drain plug (6) securely when draining is
complete.
To refill: Remove oil level plug (6) from the front of
PTO cover (26) and fill PTO assembly with lubricant
specified in Section 300-0020, LUBRICATION
SYSTEM, until oil flows from the oil level port. Install oil
level plug (6) in PTO cover (26) and tighten securely.
SPECIAL TOOLS
There are no special tools required for procedures
outlined in this section. Refer to Section 300-0070,
SERVICE TOOLS, for part numbers of general service
tools required. These tools are available from your
dealer.
* * * *
SPECIAL TORQUE SPECIFICATIONS
TORQUE
FIG. NO. ITEM NO. ITEM NAME Nm lbf ft
2 16 Locknut 950 - 1 085 700 - 800
