TermaCook Integral 800 - Page 41

41
GB
TermaCook
170
>120 40
max. 430
max. 430
max. 430
min.
100
140
255
96
≥170165
≥335
NW150
NW150
800
≥680
≥150220
≥370
Instructions for assembly
Option of outgoing air on the left or right:
depending on the installation situation, the outgo-
ing air outlet may be installed on the left or right.
Please observe the dimensions on the right/left for
optimal planning.
Option of outgoing air on the left or right:
depending on the installation situation, the outgo-
ing air outlet may be installed on the left or right.
Please observe the dimensions on the right/left for
optimal planning.
Cut-out in the base 800
Cut-out in the base 800
Worktop 600 mm
Worktop ≥ 680 mm
Outgoing air outlet on left
Outgoing air outlet on right
Outgoing air outlet on right
170
min.
100
140
255
96
40 40
max.430
max.430
max.300
Bodenausschnitt 800
≥170165
≥335
NW150
NW150
800
600
≥150220
≥370
Outgoing air outlet on left
