45
Technical data Putting the appliance into operation
Once the hob has been installed and the power supply has been
provided (mains connected) an automatic test of the controls will
be carried out and information for Customer Service will be
indicated.
Important
No items may be on the touch control sensor keys when the ap-
pliance is being connected!
Briefly wipe over the surface of the hob with a sponge and soapy
water and then dry with a clean cloth.
Instructions for assembly
Hob dimensions
Height/ Width/ Depth mm
Cooking zones
front left cm / kW
back left cm / kW
back right cm / kW
front right cm / kW
Bridge function. cm / kW
Hob kW
Fan kW
Plasma kW
170 x 800 x 520
19 x 21 / 1,6 (1,85)*
19 x 21 / 2,1 (3,00)*
19 x 21 / 1,6 (1,85)*
19 x 21 / 2,1 (3,00)*
39 x 21 / 3,7
7,4
0,115
0,01
* Power when the power boost function is activated.
