TermaTech TT22RP Manual

18 19
Leistungserklärung
TT22-CPR-2013-Version 3
Bauprodukt-Typ:
Produkttyp/Anwendung: Raumheizer für feste Brennstoff ohne Warmwasserversorgung
Art: TT22: S01-640/641, TT22S: S01-642/643, TT22H: S01-644/645,
TT22HS: S01-646/647, TT22R: S01-648/649 TT22HST: S01-650/651
TT22RP: S01-654, TT22RPS: S01-656
Brennstoff: Scheitholz
Produktions Nr.: Siehe Typenschild auf der Rückseite des Ofens
Hersteller: TermaTech A/S E-mail:
info@termatech.com
Gunnar Clausens Vej 36 Web: www.termatech.com
8260 Viby J Tel.: +45 8742 0035
Dänemark
Zertifizierung und Normen:
AVCP Systeme: Systeme 3
Europäische Norm: DS/EN 13240:2001 + A2:2004
Zertifizierung:
Die Teknologisk Institut, benannte Stelle Nr. 1235, hat die Bestimmungen des Produkt-
Typs durchgeführt und die beschriebenen Leistungen auf der Basis der Bauartprüfung
kontrolliert. Die Prüfbericht Nr. TT22 TI 300-ELAB-1778-EN + 300-ELAB-1778-EN-Rev-1.
Erklärte Leistung:
Der Unterzeichner ist für die Herstellung und die Konformität der erklärten Leistung verantwortlich.
Viby 7.3.2013 Søren Toft______________________________
Grundlegende Eigenschaften
Leistungsfähigkeit
Harmonisierte technische
Spezifizierung
Reaktion bei Brand
AI
CE/DS/EN 13240:2001 +
A2:2004
Abstand zu brennbaren Materialien
Zur Rückwand: min. 150 / 50 mm
Zur Seitenwand: min. 450 mm
In die Ecke 45°: min. 150 mm
Andere Entfernungen, Siehe Montage-
anleitung
Emission aus der Verbrennung
CO = 0,07 %
NOx = 101 mg/m³
OGC = 95 mg/m³
PM = 14 mg/m³
Elektrische Sicherheit
NPD (keine Angabe)
Maximaler Betriebsdruck
NPD (keine Angabe)
Gefahr vor herausfallender Glut
Bestanden
Oberflächentemperatur
Bestanden
Einfache Reinigung
Bestanden
Mechanische Belastbarkeit
Bestanden
Emission von gefährlichen Stoffen
Bestanden
Rauchgastemperatur
259° Celsius
Effekt
7,5 KW
Wirkungsgrad
82 %
UK
User and mounting manual
Please read also:
SUPPLEMENTARY INSTALLATION INSTRUCTIONS FOR
THE UK MARKET (last 6 pages)
CE approved according to:
EN13240
NS3058+NS3059
Congratulations on your new wood-burning stove.
We thank you for choosing a TermaTech wood-burning stove and wish you many cosy and warm
moments in the future.
Before using the stove you should read the user and mounting manual and also the SUPPLEMEN-
TARY INSTALLATION INSTRUCTIONS FOR THE UK MARKET (last 6 pages of this manual) so you
are familiar with the legal requirements as well as the instructions regarding maintenance. By this
it is ensured that the product works as it is intended and you get the most out of your investment
for many years to come.
Installation/user instruction.................................. Page 19
Installation instructions in ”smoke control areas”.. Page 21
Lighting instruction................................................ Page 21
Maintenance........................................................... Page 22
Warranty/right to invoke lack of conformity.......... Page 23
Hints...................................................................... Page 23
Remedy of malfunctions / FAQ............................... Page 24
Technical specications.......................................... Page 25
Supplementary Inst. Instructions UK..................... Page 26
Drawing concerning smoke control kit.................... Page 30
Installation mounting the soapstone TT22HST....... Page 58
INSTALLATION INSTRUCTION
(Installation mounting the soapstone TT22HST - page 58)
The stove is intended for intermittent combustion. It is not meant to “heat over” at night. By fol-
lowing the instruction below in “Lighting instructions” the best and most environmentally friendly
combustion is achieved.
The wood-burning stove is delivered ready for mounting (the exhaust branch may need to be
screwed on) and must be connected to the chimney with a smoke pipe. The connection between
stove and chimney must, as far as possible, be mounted in one straight piece (with as few bends
as possible) and as minimum horizontally, but preferably rising from the stove to the chimney.
Joints must be tight. Remember that it has to be possible to clean the pipe (possibly with a clea-
ning hatch on the pipe).
Any unauthorised changes to the wood-burning stove will be viewed as a structural change and
thereby the warranty will be void and is also a risk to safety.
In the door on your TT stove there is a spring that makes the door close by itself when you let go
of the handle.
This closing device is not a demand in the UK, Denmark and many other countries and can the-
refore be removed. In the bottom hinge the split with lentil head is removed which removes the
tension from the spring. This is most easily done by using a small screw driver and side-cutting
pliers.
National and European norms
The regulations in force at the time in question, including those that refer to national and Euro-
pean standards, must be respected when installing the wood-burning stove. Contact your local
dealer for further advice and guidance in connection with mounting. Notify your Hetas installer
before you use your wood-burning stove. It must be ensured that there is sucient airow for the
combustion in the stove, so care must be taken concerning closely shut windows and doors that
may hinder the ow of air to the combustion.
