TT23RG +TT23RGS: Distances to ammable materials using UNINSULATED uepipes*
100mm behind the stove to ammable material
700mm beside the stove to ammable material
520mm behind/beside if mounted 45° in a corner
1100mm in front of the stove to ammable material
TT23RG/ TT23RGS
TT23RG/ TT23RGS
520
520
1046
1273
1100
100
700
960
283
1100
490
490
1003
1230
1100
50
700
960
233
1100
TT23RG +TT23RGS: Distances to ammable materials using INSULATED uepipes*
50mm behind the stove to ammable material
700mm beside the stove to ammable material
490mm behind/beside if mounted 45° in a corner
1100mm in front of the stove to ammable material
TT23RG/ TT23R G S
TT23RG/ TT23R G S
520
520
1046
1273
1100
100
700
960
283
1100
490
490
1003
1230
1100
50
700
960
233
1100
*These distances only apply to the stove. Other distances apply to uepipes.
The safety distances to ammable walls for TT23RGW:
The stove have to be mount on a non-combustible wall.
700mm from the sides of the stove
340mm from oor to the bottom of the stove
1100mm from the front of the stove
Distance to non-ammable materials
It is recommended that there is a minimum of 50-100 mm behind (Except TT23RGW wallhanging)
and beside the stove so the stove can dispose of the heat, this distance makes cleaning of and
around the stove easier. In addition, refer to the relevant Building Regulations.
Requirements for the chimney
The chimney must be of sucient height so the draught conditions are okay the smoke does
not bother anyone. Good draught in the chimney is crucial to the stove working as intended and

TermaTech TT23 Series Specifications
