TerraMaster NAS - 2.2 Device Appearance

Panel Illustration: Rear Cover Illustration:
2.2 Appearance
⑤
⑥
⑦
SN
Description
Item
Power interface
USB 3.0 host
Network interface
DC 12V power input
NOTE: Do not use a third-party power adaptor.
Use to connect USB storage device or USB wireless adaptor
1000M/100M bps network interface
①
②
③
④
SN
⑤
⑥
⑦
SN
Item
Item
Hard drive tray
Network indicator
Power switch/Power indicator
Hard drive indicator
Power interface
USB 3.0 host interface
Network interface
3
Model:F4-421
