2. SPECIFICATIONS
2-1 Electrical Specifications
Measurement Range :
Type J :
-200℃ to 760℃
-328℉ to 1400℉
Type K :
-200℃ to 1370℃
-328℉ to 2498℉
Resolution : 0.1℃ , 1℃ , 0.2℉ , 2℉
Maximum Voltage at Thermocouple Input :
60V dc ,or 24Vrms ac
RF Field Derating :
Strong RF fields and low-frequency adversely affect accurate
measurement .
Operating Temperature and Humidity:
0℃ to 40℃ (32℉ to 104℉ ), 0 - 80％RH
Storage Temperature and Humidity:
-10℃ to 60℃ (14℉ to 140℉ ), 0 - 70％RH
2
Basic Accuracy: ( @23± 5℃ Calibration ) Accuracy are± ( ...％ of
reading + degree ) at 18℃ to 28℃ with relative humidity up to 80％
For single thermocouple measurements
Function
Resolution
Range
Accuracy
Type K
Type J
℃
0.1℃
-200℃~-50℃
-200℃~-50℃
(0.5%rdg+1.0℃)
-50℃~0℃
-50℃~0℃
(0.2%rdg+1.0℃)
0℃~200℃
0℃~150℃
(0.1%rdg+ 0.8℃)
1℃
200℃~1370℃
150℃~760℃
(0.2%rdg+ 2℃)
℉
0.2℉
-328℉~-58℉
-328℉~-58℉
(0.5%rdg+ 2.0℉)
-58℉~32℉
-58℉~32℉
(0.2%rdg+ 2.0℉)
32℉~392℉
32℉~302℉
(0.1%rdg+1.6℉)
2℉
392℉~2498℉
302℉~1400℉
(0.2%rdg+3℉)
For T1-T2 Measurements accuracy is Basic accuracy add 0.2%rdg.
NOTE
The basic accuracy specification does not include the error of the
probe. Please refer to the probe accuracy specification for
additional details.
Temperature Coefficient:
For ambient temperatures from 0℃ to 18℃ and 28℃ to 40℃
