Battery Life ：500hrs approx.
Polarity ： Automatic polarity “
“ indicates negative
input.
Auto Power Off Time ：Approx. 10 minutes
Operating Temperature
：
0
℃
to 40
℃
( 32
℉
to 104
℉
)
and Humidity below 80% RH
Storage Temperature ：-10℃ to 60℃ ( 14℉ to 140℉ )
and Humidity below 70% RH
Dimensions ：180 (L)
×
82 (W)
×
38(H) mm
Weight ：Approx. 365
g
Accessories ： Test leads, Spare fuse (0.5A/250V), Battery
and Instruction manual.
3-2 Electrical Specifications
Accuracies are ± (...% of reading + ...digits) at 23℃± 5℃,below 80% RH.
DC Voltage : ( Autoranging & Manual range )
Range Resolution Accuracy
Input
Impedance
Overload
Protection
320mV 0.1mV
> 100M
Ω
3.2V 1mV
11M
Ω
32V 10mV
320V 100mV
0.5%+2
600V 1V 0.8%+2
10M
Ω
AC/DC 750V
4
AC Voltage : 40Hz〜400Hz ( Autorange & Manual range )
Range Resolution Accuracy
Input
Impedance
Overload Protection
3.2V 100uV
11M
Ω
32V 1mV
320V 10mV
600V 1V
1.2%+4
10M
Ω
AC/DC 750V
DC Current : (uA mA Autoranging & Manual Range)
Range Resolution Accuracy
Burden
Voltage
Overload Protection
320uA 0.1uA 0.2V max
3200uA 1uA 1.8V max
32mA 10uA 1.2V max
320mA 100uA
1%+2
1.8V max
0.5A/250V fast blow fuse
& Diode
20A 10mA 1.5%+2 0.6V max
20A/380V fast blow fuse
10A Continuity
20A for 30 sec. max.
AC Current : 40Hz〜400Hz ( uA mA Autorange & Manual range )
Range Resolution Accuracy
Burden
Voltage
Overload Protection
320uA 0.1uA 0.2V max
3200uA 1uA 1.8V max
32mA 10uA 1.2V max
320mA 100uA
1.5%+5
1.8V max
0.5A/250V fast blow fuse
& Diode
20A 10mA 2.0%+5 0.6V max
20A/380V fast blow fuse
10A Continuity
20A for 30 sec. max.
