TES TES-2700 - PARTS & CONTROLS; Name of Parts and Positions

Resistance: ( Autoranging & Manual range )
Range Resolution Accuracy
Open Circuit
Voltage
Overhead
protection
320
Ω
0.1
Ω
3.2K
Ω
1
Ω
32K
Ω
10
Ω
320K
Ω
100
Ω
3.2M
Ω
1K
Ω
0.8%+ 2
30M
Ω
10K
Ω
1.5%+ 3
1.3V 660Vrms
Diode Test: ( )
Range Resolution
Short Circuit
Current
Accuracy
Open Circuit
Voltage
Overload
Protection
1mV 0.8mA typical 1%+ 2 3V 660Vrms
Audible Continuity:
Range Resolution Max Open Circuit Voltage Overload Protection
≦
20
Ω
1.3V 660Vrms
6
4. PARTS & CONTROLS
4-1 Name of Parts and Positions:
(Fig-1)
7
