Tesco CDGT0216 - Component Identification; Adjustment; Adjusting Height; Adjusting Cutting Angle

Original InstructionsTesco CDGT0216
7
a
b
c
d
e
f
g
h
i
1)
1!
1@
1#
1$
CONTROLS & FEATURES
On/O trigger1.
Upper handle2.
Front handle3.
Handle lock knob4.
Cable hook5.
Handle mounting ring6.
Shaft locking collar7.
Shaft8.
Motor body9.
Rotation lock10.
Angle adjust button11.
Guard12.
Line cutting blade13.
Trimming line14.
Wheel for edge trimming (tting is optional)15.
