8
Figure 1.3.b 30 kVA Fuses and Switches Panel
S5
(Battery Input, F10-F11-F12)
S1
(AC Input, F1-F2-F3)
S3
(Maintenance By-pass)
S2
(By-Pass, F4-F5-F6)
S4
(AC Output, F7-F8-F9)
COM1 - RS232
Communication Socket
(DB9 Female)
S7
On / Off
Switch
SNMP Adapter
(Optional)
COM2 - RS232
Communication Soc
ket
(DB9 Female)
Relay Output Contacts and Inputs
Battery
Circuit
Breaker
Generator
input
Repo
input
TH1
Sensor
Relay
2
Relay
3
Relay
4
Parallel Port 2
(Optional)
Parallel Port 1
(Optional)
