5
ENG
EXTERNAL DEVICE CONNECTION DIAGRAM
DVD Set-top boxes
AV input connection
AV input connectionAV input connection
AV output connection
USB connection
TV connection
RJ45 connection
HDMI input connection
TV INSTALL AND CONNECT
Set your TV
To put your TV on a firm place which can
bearthe weight of the TV.
To avoid danger, please don’t positions the
TV near water or heating place (such as light,
candle, heating machine),do not block the
ventilation at the back of TV.
Connect antenna and power
1. Connect the antenna cable to the antenna
socket on the back of the TV.
2. To plug the power cord of TV (AC 100-
240V~ 50/60Hz).
Turn on TV
3. Connect the power supply, enter the
standby mode (red light), press the power
button of the TV or the power button on the
remote control toturn on the TV
Note:
Note: If the model has a CI card slot on its top, a
silicone plug for the CI card slot can be found in the
accessory bag (for models without CI card slot, there is
no such silicone plug), please insert the silicone plug
into the slot when the CI card is not in use.
TV signal output
Note: Picture for reference purposes only.
