Brakes Specifications
Rear Brake Pad Thickness (excluding back
plate)
0.354”/9 mm
Parking brake Electrically actuated parking brake calipers
Brake Disc Friction Pair
Front: .31"/8 mm
Rear: .28"/7 mm
Suspension
Suspension Specifications
Front Independent, double wishbone, air spring or coil spring/telescopic damper, sway bar
Rear Independent, multi-link, air spring or coil spring/telescopic damper, sway bar (air suspension vehicles
only)
Battery - Low Voltage
Battery -
Low Voltage
Specifications
Rating 33 amp hour or higher
Voltage and Polarity Low voltage
negative (-) ground
Battery - High Voltage
Battery - High Voltage Specifications
Type Liquid-cooled lithium ion (Li-ion)
Nominal Voltage 350 V DC
Temperature Range Do not expose
Model S to ambient temperatures above 140° F (60° C) or below -22° F
(-30° C) for more than 24 hours at a time.
Subsystems
185Specifications
