• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician to help.
CAUTION: This equipment and its antennas must not be co-located or operated with another antenna or
transmitter.
RF Modules
The devices described below have been evaluated against the essential requirements of the 2014/53/EU.
Description Frequency Band Power Level Antenna Location Manufacturer
Security Controller 2400-2483.5MHz 2.5 mW PCB Antenna, in center console
Tesla, Inc.
3500 Deer Creek Rd
Palo Alto, CA 94304 USA
Security Controller 13.56 MHz
n/a
(magnetic
field)
PCB Antenna, in center console
Rear Fascia
Endpoint
2400-2483.5 MHz 2.5 mW PCB Antenna, behind rear fascia
Pillar Endpoint 2400-2483.5MHz 2.5 mW PCB Antenna, behind the B-pillar
glass
Pillar Endpoint 13.56 MHz n/a
(magnetic
field)
PCB Antenna, behind the B-pillar
glass
TPMS Sensor 2400-2483.5 MHz 2.5 mW Each wheel
FM 76-108 MHz n/a (receive
only)
Rear Window
Harman Becker Automotive
Systems GmbH
Becher-Goring-Str.16
76307 Karlsbad, Deutschland
DAB 174-241 MHz n/a (receive
only)
Rear Window
Homelink (if
equipped)
433.9 MHz 10 mW Above front bumper beam
Gentex Corporation
600 N Centennial Street
Zeeland, MI 49464 USA
Radar 76000-77000 MHz 4 W Above front bumper beam
ADC Automotive Distance
Control Systems GmbH
Peter-Dornier-Strasse 10
88131 Lindau, Germany
Bluetooth 2400-2483.5 MHz 2.5 mW max.
A-header left side
A-header right side, wireless
connectivity
Tesla, Inc.
3500 Deer Creek Rd
Palo Alto, CA 94304 USA
GSM 900
885-915
930-960 MHz
2 W
Transmit and receive - A-header
right side, also used for eCall
Receive - A-header left side
A-header (MIMO)
Wireless Connectivity
GSM 1800
1710-1785
1805-1880 MHz
1 W
Radio Regulatory Compliance
206 MODEL Y Owner's Manual
