Description Frequency Band Power Level Antenna Location Manufacturer
WCDMA (band 8)
909-915
954-960 MHz
250 mW
WCDMA (band
1/3)
1920-1980
2110-2170 MHz
250 mW
LTE (band 7/8) for
Car PC models
1098058 and
1506277
2500-2570, 909-915
MHz
2620-2690, 954-960
MHz
200 mW
LTE (band 20/28)
for Car PC models
1098058 and
1506277
832-862,698-748 MHz
791-821, 758-803 MHz
200 mW
LTE (band 1/3) for
Car PC models
1098058 and
1506277
1940-1965, 1735-1765
MHz
2130-2155, 1830-1860
MHz
200 mW
LTE (band
7/8/34/41) for Car
PC model 1960100
2500-2570, 2620-2690
MHz
925-960, 880-915 MHz
2010-2025 MHz (TDD)
2496-2690 MHz (TDD)
200 mW
LTE (band
20/28/29/32) for
Car PC model
1960100
758-803, 703-748 MHz
791-821, 832-862 MHz
717-728 MHz (RX only)
1452-1496 MHz (RX
only)
200 mW
LTE (band 1/3/9)
for Car PC model
1960100
1805-1880, 1710-1785
MHz
2110-2170, 1920-1980
MHz
200 mW
LTE (band 11/17/18)
for Car PC model
1960100
1475.9-1495.9,
1427.9-1447.9
860-890, 815-845 MHz
200 mW
Wi-Fi
2400-2483.5 MHz
5470-5725 MHz,
5725-5850 MHz
100 mW
A-header left side
A-header right side, Wireless
Connectivity
GNSS
1563-1587 MHz,
1593-1610 MHz
n/a (receive
only)
Between windshield and rear
view mirror
Wireless Charger 127.7KHz n/a
(magnetic
field)
PCB antenna, in center console
Radio Regulatory Compliance
