6
ENG
Levelling feet
L
H
The picture above is only for reference. The actual configuration will depend on the physical product or
statement by the distributor.
Adjusting procedures:
a. Turn the feet clockwise to raise the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust the right and left feet based on the procedures above to a horizontal level.
Door right-left change
List of lools to be provided by the user
Cross screwdriver
Putty knife
thin-blade screwdriver
5/16’’
socket and ralchet
Masking tape
Parts to be used for door reverse
SN Part Quantity Notes
1 Upper hinge 1
Pre-installed on refrigerator, removed and retained it when changing
the door
2 Upper hinge cover 1
Pre-installed on refrigerator, removed and retained it when changing
the door
3 Decorative cover 1
Pre-installed on refrigerator, removed and retained it when changing
the door
4 Door self-locking 2
Pre-installed on refrigerator, removed and retained it when changing
the door
5 Middle hinge 1 Pre-installed on the refrigerator and to be used when changing the door
6 Decorative cover 1 Pre-installed on the refrigerator and to be used when changing the door
7 Lower hinge 1 Pre-installed on the refrigerator and to be used when changing the door
8 Levelling feet 1 Pre-installed on the refrigerator and to be used when changing the door
9 Left upper hinge 1 In the attached plastic bag, take them out for use when door is reversed
10 Left upper hinge cover 1 In the attached plastic bag, take them out for use when door is reversed
11 Left door self-locking 2 In the attached plastic bag, take them out for use when door is reversed
12 Right plastic cover 1 In the attached plastic bag, take them out for use when door is reversed
