PRODUCT OVERVIEW
Product Specifications
This manual applies to Wall Connectors identified by part number 1734412-XX-X.
Voltage and Wiring Nominal 200-240 V AC single-phase
Current Output Range 12 – 48 amps
Terminal Blocks 12-4 AWG G (3.5 - 25 mm2), copper
Supported Conduit Sizing ¾" (21 mm) default, 1" (27 mm) optional
Grounding Scheme TN/TT
Frequency 50/60 Hz
Cable Length 24 ft (7.3 m)
Wall Connector Dimensions
Height: 13.6 in (345 mm)
Width: 6.1 in (155 mm)
Depth: 5.9 in (150 mm)
Wire Box Bracket Dimensions
Height: 9.8 in (250 mm)
Width: 4.7 in (120 mm)
Depth: 3.5 in (90 mm)
Weight (including wirebox) ~13lbs (5.7kg)
Operating Temperature -22˚F to 122˚F (-30˚C to 50˚C)
Storage Temperature -40˚F to 185˚F (-40˚C to 85˚C)
Enclosure Rating Type 3R
IP 54
Ventilation Not required
Means of Disconnect External branch circuit breaker
Wi-Fi 2.4 GHz, 802.11b/g/n
Agency Approvals ETL/cETL
6Universal Wall Connector Manual
