PULLER-TENSIONER
Model: AFB506
Manual: MI-AFB506-149-00-GB
NOTE: in this case, although the lever (table 1, pos. 34) is not active, the dynamometer
(table 1, pos. 30) and the relevant electric pull control device are working.
Therefore, both the electric pull control devices must be set as previously described.
Pull values can be read on the two scales engraved on the ring
nut of each dynamometer (table 1, pos. 30-36).
NOTE: vacuum brakes engage automatically when the lever (table 1, pos. 40) is moved
to central position.
WARNING: do not move the lever (table 1, pos. 40) fast from working position to central
neutral position. This operation could damage the negative safety brakes discs that
have to bear a heavy load.
By moving the levers (table 1, pos. 34-40) to position
(upwards), ropes can be manually strung (without control on the
pull).
ATTENTION: never touch the selector (table 1, pos. 38) while the machine is working.
