Chapter 7 – Maintenance
TestEquity 3007C Temperature Chamber Page 7-13
Major Electrical Parts
Description
Mfr
Mfr Part No.
Ref #
Part #
Qty
UOM
Audible Alarm
Floyd Bell
MC-09-201-Q
AL1
200005
1
ea
Arc Suppressor
ITW Paktron
104MACQRL150
AS1, 2, 5
200296
3
ea
Contactor, 3 P 30A
Hartland
HCC-3XT02SX
C1-3
200245
3
ea
Relay, Octal DPDT 10A 120VAC
Idec
RR2P-UCAC120
CR1, 3, 4
200292
3
ea
Relay, SPDT 5A 120VAC
Omron
G2R-1-T-AC120
CR5
200160
1
ea
Disconnect Switch, 3 Pole, 45A
ABB
OT63F3
DSW
200281
1
ea
Fuse, 4A
Bussman
FNQ-R-4
F1, 2
200083
2
ea
Fuse, 3A
Bussman
FNM-3
F3
200186
1
ea
Fuse, 20A
Bussman
FNQ-R-20
F4-6
200242
3
ea
Fuse, 20A
Bussman
LP-CC-20
F7-12
200206
6
ea
Circulator Motor, 230V 1725 RPM
CUSTOM
CUSTOM
FM3, 4
222330
2
ea
Heat Limiter
Thermodisc
G5A-01-240C
HL1-3
200070
3
ea
Heater, Air
CUSTOM
CUSTOM
HT1
222340
1
ea
Appliance Light, 40W, 120V
Generic
Generic
LT1
300096
1
ea
Indicator, Panel, 240V Neon
SoLiCo
S412-2-1-N2
PL1
200026
1
ea
Indicator, Panel, 120V Neon
SoLiCo
S412-2-1-N1
PL2
200025
1
ea
Relay, Phase Control
Peltec
256-240S
PCR1
222292
1
ea
Resistor, 10 k, 5 W
Vishay/Dale
71-RH00510K00FE02
R1
222334
1
ea
Solid State Relay, 25A
Idec
RSSDN-25A
SSR1, 2
200021
2
ea
Solid State Relay, 10A
Omron
G3NE-210T-US DC5
SSR3-6
200129
4
ea
Solid State Relay, 5A
Omron
G3NA-205B-DC5-24
SSR7-9
200032
3
ea
Switch, SPST, Rocker
Carlingswitch
LRA211-RA-B/125N
SW1
200023
1
ea
Switch, ON-OFF-ON
Carlingswitch
RC911-RA-B-0-N-XLR1
SW2
200275
1
ea
F4 Temperature Controller
Watlow
F4SH-CKA0-01AE
TCR1
200001
1
ea
F4T Temperature Controller
Watlow
F4T1L2EAA2E1017
TCR1
222510
1
ea
High/Low Limit Controller
Watlow
PM6L1AJ-AAAABBS
TCR2
200301
1
ea
Timing Module
Airotronics
THCU30SC
TM1
200287
1
ea
Control Transformer
Hammond
PH350MLI
TR1
200219
1
ea
Chart Recorder Option
Recorder, 1 Pen, 10"
Honeywell
DR4301-0000-G0100
RCD1
200094
1
ea
Chart paper, -90 to 210 C
Honeywell
24001660-034
200095
1
ea
Chart paper, -130 to 410 F, Alternate
Honeywell
24001660-033
200096
1
ea
Pen, Purple, Six Pack
Honeywell
30735489-007
200097
1
ea
