TESTO 177 - Humidity Calibration (testo 177-H1); Configuring Display Functions; Enabling Limit Signal Output

21
7. Programming
Humidity calibration ( testo 177-H1 only):
Select between Factory defaults or Custom .
If Custom is selected, the Custom ... button is activated.
Click on Custom ... .
- The Humidity calibration window opens.
Carry out humidity calibration using the control and adjustment
set (Part no. 0554.0660). Follow the instructions in the
Instruction Manual for the Control and Adjustment Set.
Display functions:
Select whether the LEDs, the Alert led , Status led and Display
on are to be activated in the data logger.
Only the data display is deactivated when the display is
switched off. Status information on mode and battery capacity
are always shown.
Enable limit signal output
From ComSoft Version 3.4 on, the external alarm signal output
testo 581 can be activated if connected to a data logger.
