15
Using the product
For reliable measurements it is necessary to use reflective
markers. To apply the reflective marker, wait until the object to
be measured has come to a standstill.
The ideal distance to the measurement object is between 10
and 40 cm. During the measurement, always aim at the
reflective marker from an angle of approx.30°. This avoids
multiple reflections from the surface.
If no reflective marker can be attached, it must be checked
whether the reflective properties of a reflective point on the
measurement object are sufficient for rpm measurement. In
this case, aim at the measurement object from the vertical, and
check whether a value is displayed. If the measurement object
displays several reflections per revolution, (e.g. reflective
ventilator with 5 vanes), the number of the impulses per
revolution (e.g. number of ventilator vanes) must be entered
into the instrument (see below) in order to obtain correct rpm
measurements.
²
Switching tthe iinstrument oon:
i Press .
- Measuring mode is opened.
²
Switching tthe ddisplay llight oon:
The instrument is switched on.
i Press .
- The display light goes out automatically if no key is
pressed for 10 seconds.
²
Changing tthe ddisplay vvie
w/setting tthe nnumber oof bblades:
As an alternative to entering the impulses per revolution,
the setting NO.1 can be selected and the rpm calculated
manually from the measurement value (measurement value
divided by impulse/number of vanes)
Adjustable views/setting the number of blades
· Hold: Readings are held.
· Max: Maximum values since the start of the last measurement.
· Min: Minimum values since the start of the last measurement.
· NO.: Set the number of blades. Change the value with .
i Press several times until the desired view appears.
de
en
fresitptsvnl????
