5 First steps
21
Switch the imager on/off
1. Remove protection cap from the lens.
2. Press [
].
- The start screen appears on the display. The type designation
of the imager and the firmware version are shown.
- The measurement view is opened after the warm-up period.
- The imager performs an automatic zeroing approx. every 60
sec. This can be recognized by means of a "click". The image is
frozen briefly when this occurs.
> To switch off: Press [
].
- The display goes out and the imager is switched off.
Focus image using motor focus
> Slide [Motor focus switch] towards the display (position:
).
> Move [Motor focus control] until the image is in focus.
Manually focusing the image
NOTICE
Possible damage to the auto mechanism!
> Only use Rotating ring with the motor focus switched off.
> Slide [Motor focus switch] towards the lens (position: ).
> Turn Rotating ring of the lens until the image is in focus.
