Table 3-20. Ethernet Media Access Controller (EMAC) Terminal Functions (continued)
SIGNAL
POWER
TYPE
(1)
PULL
(2)
DESCRIPTION
GROUP
(3)
NAME NO.
MDIO
SPI0_SCS[0] / TM64P1_OUT12 / GP1[6] / MDIO /
D17 I/O CP[10] A MDIO serial data
TM64P1_IN12
SPI0_SCS[1] / TM64P0_OUT12 / GP1[7] / MDCLK /
E16 O CP[10] A MDIO clock
TM64P0_IN12
