Table 3-24. Universal Host-Port Interface (UHPI) Terminal Functions (continued)
SIGNAL
POWER
TYPE
(1)
PULL
(2)
DESCRIPTION
GROUP
(3)
NAME NO.
PRU0_R30[30] / UHPI_HINT / PRU1_R30[11] / GP6[12] R16 O CP[23] C UHPI host interrupt
PRU0_R30[31] / UHPI_HRDY / PRU1_R30[12] /GP6[13] R17 O CP[23] C UHPI ready
RESETOUT / UHPI_HAS / PRU1_R30[14] / GP6[15] T17 I CP[21] C UHPI address strobe
