AM1808

SPRS653E –FEBRUARY 2010–REVISED MARCH 2014

www.ti.com

Table 6-10. PSC1 Default Module Configuration

LPSC Module Name Power Domain Default Module State Auto Sleep/Wake Only

Number

0 EDMA3 Channel Controller 1 AlwaysON (PD0) SwRstDisable —

1 USB0 (USB2.0) AlwaysON (PD0) SwRstDisable —

2 USB1 (USB1.1) AlwaysON (PD0) SwRstDisable —

3 GPIO AlwaysON (PD0) SwRstDisable —

4 UHPI AlwaysON (PD0) SwRstDisable —

5 EMAC AlwaysON (PD0) SwRstDisable —

6 DDR2 (and SCR_F3) AlwaysON (PD0) SwRstDisable —

7 McASP0 ( + McASP0 FIFO) AlwaysON (PD0) SwRstDisable —

8 SATA AlwaysON (PD0) SwRstDisable —

9 VPIF AlwaysON (PD0) SwRstDisable —

10 SPI 1 AlwaysON (PD0) SwRstDisable —

11 I2C 1 AlwaysON (PD0) SwRstDisable —

12 UART 1 AlwaysON (PD0) SwRstDisable —

13 UART 2 AlwaysON (PD0) SwRstDisable —

14 McBSP0 ( + McBSP0 FIFO) AlwaysON (PD0) SwRstDisable —

15 McBSP1 ( + McBSP1 FIFO) AlwaysON (PD0) SwRstDisable —

16 LCDC AlwaysON (PD0) SwRstDisable —

17 eHRPWM0/1 AlwaysON (PD0) SwRstDisable —

18 MMCSD1 AlwaysON (PD0) SwRstDisable —

19 uPP AlwaysON (PD0) SwRstDisable —

20 ECAP0/1/2 AlwaysON (PD0) SwRstDisable —

21 EDMA3 Transfer Controller 2 AlwaysON (PD0) SwRstDisable —

22-23 — — — —

24 SCR_F0 (and bridge F0) AlwaysON (PD0) Enable Yes

25 SCR_F1 (and bridge F1) AlwaysON (PD0) Enable Yes

26 SCR_F2 (and bridge F2) AlwaysON (PD0) Enable Yes

27 SCR_F6 (and bridge F3) AlwaysON (PD0) Enable Yes

28 SCR_F7 (and bridge F4) AlwaysON (PD0) Enable Yes

29 SCR_F8 (and bridge F5) AlwaysON (PD0) Enable Yes

30 Bridge F7 (DDR Controller AlwaysON (PD0) Enable Yes

path)

31 On-chip RAM (including PD_SHRAM Enable —

SCR_F4 and bridge F6)
