PCM1808 Evaluation Module
6.2 Bill of Materials
Table 4 lists the EVM bill of materials.
Table 4. Bill of Materials
Designator QTY Description Part Number Manufacturer
!PCB1 1 Printed Circuit Board DC015 Any
C1, C9 2 CAP, CERM, 1 uF, 16 V, ±10%, X7R, 0805 GRM21BR71C105KA01L MuRata
C2, C4, C6 3 CAP, CERM, 10 uF, 16 V, ±10%, X7R, 0805 CL21B106KOQNNNE Samsung Electro-
Mechanics
C3, C5, C7 3 CAP, CERM, 0.1 uF, 50 V, ±10%, X7R, 0402 C1005X7R1H104K050BB TDK
C8, C10 2 CAP, CERM, 0.01 uF, 50 V, ±10%, X7R, 0805 08055C103KAT2A AVX
C11, C15,
C18
3 CAP, CERM, 0.1 uF, 16 V, ±10%, X7R, 0402 GCM155R71C104KA55D MuRata
C12, C13 2 CAP, CERM, 33 pF, 50 V, ±5%, C0G/NP0, 0402 C1005C0G1H330J050BA TDK
C14, C17 2 CAP, CERM, 10 uF, 16 V, ±20%, X5R, 0603 GRM188R61C106MAALD MuRata
C16 1 CAP, CERM, 0.01 uF, 16 V, ±10%, X5R, 0402 GRM155R61C103KA01D MuRata
D1 1 LED, Green, SMD LTST-C170KGKT Lite-On
H1, H2, H3,
H4
4 Bumpon, Hemisphere, 0.25 X 0.075, Clear SJ5382 3M
J1, J2, J3,
J4, J5, J6,
J7, J8
8 Header, 100mil, 3x1, Gold, TH TSW-103-07-G-S Samtec
J9 1 RCA Jack, 1Pos, Tin, Red, R/A, TH RCJ-012 CUI Inc.
J10 1 RCA Jack, 1Pos, Tin, White, R/A, TH RCJ-013 CUI Inc.
J11 1 Terminal Block, 3.5mm Pitch, 2x1, TH ED555/2DS On-Shore Technology
L1 1 Ferrite Bead, 220 ohm @ 100 MHz, 2.2 A, 0603 MPZ1608S221A TDK
R1, R2, R3,
R4
4 RES, 47.0, 1%, 0.1 W, 0603 RC0603FR-0747RL Yageo
R5 1 RES, 442, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW0603442RFKEA Vishay-Dale
R6, R7, R8 3 RES, 10.0 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW060310K0FKEA Vishay-Dale
R9, R10 2 RES, 100, 1%, 0.125 W, AEC-Q200 Grade 0, 0805 CRCW0805100RFKEA Vishay-Dale
R11 1 RES, 1.0 M, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 CRCW04021M00JNED Vishay-Dale
R12 1 RES, 0, 5%, 0.063 W, 0402 RC0402JR-070RL Yageo America
SH1, SH2,
SH3, SH4
4 Shunt, 100mil, Gold plated, Black SNT-100-BK-G Samtec
TP1, TP2,
TP3
3 Test Point, Miniature, Yellow, TH 5004 Keystone
TP4 1 Test Point, Compact, Red, TH 5005 Keystone
TP5 1 Test Point, Compact, White, TH 5007 Keystone
TP6, TP7 2 Test Point, Miniature, Black, TH 5001 Keystone
U1 1 99dB SNR Stereo ADC with Single-Ended Inputs, PW0014A
(TSSOP-14)
PCM1808PWR Texas Instruments
U2 1 Crystal Oscillator Driver, DCK0006A (SOT-SC70-6) SN74LVC1GX04DCKR Texas Instruments
U3 1 Single Output Low Noise LDO, 400 mA, Fixed 3.3 V Output,
1.7 to 5.5 V Input, with Reverse Current Protection, 5-pin
SOT-23 (DBV), -40 to 85 degC, Green (RoHS & no Sb/Br)
TPS73633DBVR Texas Instruments
Y1 1 Crystal, 12.288 MHz, 20 pF, SMD ECS-122.8-20-5PX-TR ECS Inc.
7 Related Documentation
1. Texas Instruments, PCM1808 Single-Ended, Analog-Input 24-Bit, 96-kHz Stereo ADC Data Sheet
