Control Register File
CPU Data Paths and Control2-14 SPRU733
Table 27. Control Status Register (CSR) Field Descriptions
Bit Field Value Description
3124 CPU ID 0FFh Identifies the CPU of the device. Not writable by the MVC instruction.
01h Reserved
2h C67x CPU
3h C67x+ CPU
4hFFh Reserved
2316
REVISION ID 0FFh Identifies silicon revision of the CPU. For the most current silicon
revision information, see the device-specific data manual. Not writable
by the MVC instruction.
1510 PWRD 03Fh Power-down mode field. See Figure 25. Writable by the MVC instruction.
0 No power-down.
1h8h Reserved
9h Power-down mode PD1; wake by an enabled interrupt.
Ah10h Reserved
11h Power-down mode PD1; wake by an enabled or nonenabled interrupt.
12h19h Reserved
1Ah Power-down mode PD2; wake by a device reset.
1Bh Reserved
1Ch Power-down mode PD3; wake by a device reset.
1D3Fh Reserved
9
SAT Saturate bit. Can be cleared only by the MVC instruction and can be set
only by a functional unit. The set by a functional unit has priority over a
clear (by the MVC instruction), if they occur on the same cycle. The SAT
bit is set one full cycle (one delay slot) after a saturate occurs. The SAT
bit will not be modified by a conditional instruction whose condition is false.
0 Any unit does not perform a saturate.
1 Any unit performs a saturate.
8
EN Endian mode. Not writable by the MVC instruction.
0 Big endian
1 Little endian
