Texas Instruments TPA3255EVM - Page 15

www.ti.com Board Layouts, Bill of Materials, and Schematic
15
SLOU441–July 2016
Submit Documentation Feedback
Copyright © 2016, Texas Instruments Incorporated
TPA3255EVM
Table 8. Bill of Materials (continued)
Designator
Quantit
y
Value Description
Package
Reference
Part NUmber Manufacturer
C49 1 0.01 µf CAP, CERM, 0.01 µF, 50
V, ± 10%, X7R, 0603
603 GRM188R71H103KA
01D
MuRata
D1 1 100 V Diode, Schottky, 100 V, 1
A, SMA
SMA B1100-13-F Diodes Inc.
D2 1 Orange LED, Orange, SMD LED_0805 LTST-C170KFKT Lite-On
D3 1 100 V Diode, Schottky, 100 V, 3
A, SMA
SMA SK310A-TP Micro Commercial
Components
D4 1 Red LED, Red, SMD LED_0805 LTST-C170KRKT Lite-On
D5 1 Green LED, Green, SMD LED_0805 LTST-C171GKT Lite-On
H1 1 Heat Sink, Vertical Heatsink ATS-TI1OP-519-C1-
R3
Advanced
Thermal Solutions
H2, H3, H4, H5,
H6, H12, H13
7 MACHINE SCREW PAN
PHILLIPS M3 5mm
Screw M3 Phillips
head
MPMS 003 0005 PH B&F Fastener
Supply
H7, H8, H9,
H10, H11
5 Standoff, Hex, 25-mm
Length, M3, Aluminum
Standoff M3 24438 Keystone
J1, J2, J9 3 Dual Binding Posts with
Base, 2x1, TH
Dual Binding
Posts with Base,
2 × 1, TH
6883 Pomona
Electronics
J3 1 RCA Jack, Vertical, Red,
TH
RCA JACK, RED RCJ-022 CUI Inc.
J4, J5, J6, J7,
J8, J19, J26,
J27
8 Header, 100 mil, 3 × 1,
Gold, TH
PBC03SAAN PBC03SAAN Sullins Connector
Solutions
J10, J12 2 Header, 2.54 mm, 3 × 1,
TH
Header, 2.54 mm,
3 × 1, TH
22-11-2032 Molex
J11, J20 2 Binding Post, BLACK, TH 11.4 mm × 27.2
mm
7007 Keystone
J14 1 RCA Jack, Vertical, Black,
TH
RCA Jack,
Vertical, Black,
TH
RCJ-021 CUI Inc.
J15 1 RCA Jack, Vertical, Blue,
TH
RCA Jack,
Vertical, Blue, TH
RCJ-025 CUI Inc.
J16 1 Header, 100 mil, 4 × 2, Tin,
TH
Header, 4 × 2,
100 mil, Tin
PEC04DAAN Sullins Connector
Solutions
J17 1 Header (friction lock), 100
mil, 4 × 1, Gold, TH
Header 4 × 1
keyed
22112042 Molex
J18 1 RCA Jack, Vertical, White,
TH
RCA JACK,
WHITE
RCJ-023 CUI Inc.
J21, J30 2 Header, 100 mil, 2 × 1,
Gold, TH
Sullins 100 mil, 1
× 2, 230 mil
above insulator
PBC02SAAN Sullins Connector
Solutions
J22, J23, J24,
J25, J29
5 JUMPER TIN SMD 6.85 mm × 0.97
mm × 2.51 mm
S1911-46R Harwin
J28 1 Receptacle, 100 mil, 8 × 2,
Gold, TH
Receptacle, 8 ×
2, Body 21.08
mm × 4.95 mm,
Pitch 2.54 mm
SSQ-108-02-G-D Samtec
L1 1 100 µH Inductor, Shielded Drum
Core, Ferrite, 100 µH, 1.5
A, 0.165 Ω, SMD
10 mm × 5 mm ×
10 mm
7447714101 Wurth Elektronik
L2, L3, L4, L5 4 10 µH Inductor, Toroid, Powdered
Iron, 10 µH, 6.1 A, 0.026
Ω, TH
28.6 mm × 12.3
mm
MA5172-AE Coilcraft
L6 1 10 µH Inductor, Wirewound, 10
µH, 0.8 A, 0.204 Ω, SMD
2-Pin SMD, Body
4 mm × 4 mm,
Height 1.2 mm
NRS4012T100MDGJ
V
Taiyo Yuden
