TPA3255EVM
Table 8. Bill of Materials (continued)
Designator
Quantit
y
Value Description
Package
Reference
Part NUmber Manufacturer
U4 1 150W Stereo/300W MONO
PurePath HD Analog-input
Power Stage, DDV0044D
DDV0044D TPA3255D2DDVR Texas
Instruments
U5, U6 2 Dual Low-Noise
Operational Amplifier, 10 to
30 V, 0 to 70 degC, 8-pin
SOIC (D0008A), Green
(RoHS& no Sb/Br)
D0008A NE5532ADR Texas
Instruments
U7 1 ULTRA-SMALL SUPPLY
VOLTAGE
SUPERVISORS,
DCK0005A
DCK0005A TPS3802K33DCKR Texas
Instruments
C73, C74, C75,
C76
0 22 pF CAP, CERM, 22 pF, 50 V,
± 5%, C0G/NP0, 0603
603 GRM1885C1H220JA
01D
MuRata
C77, C78, C79,
C80
0 1 µf CAP, CERM, 1 µF, 50 V, ±
10%, X7R, 1206
1206 GRM31MR71H105KA
88L
MuRata
FID1, FID2,
FID3, FID4,
FID5, FID6
0 Fiducial mark. There is
nothing to buy or mount.
N/A N/A N/A
J13 0 Header, 100 mil, 2 × 1,
Gold, TH
Sullins 100 mil, 1
× 2, 230 mil
above insulator
PBC02SAAN Sullins Connector
Solutions
R47, R49, R50,
R51
0 10.0 k RES, 10.0 k, 1%, 0.1 W,
0603
603 CRCW060310K0FKE
A
Vishay-Dale
R53, R54, R55,
R56
0 3.3 RES, 3.3, 5%, 0.75 W,
2010
2010 CRCW20103R30JNE
F
Vishay-Dale
TP1, TP2, TP3,
TP4, TP5, TP6,
TP7, TP8, TP9,
TP10, TP11,
TP12, TP13,
TP14
0 Test Point, Multipurpose,
Grey, TH
Grey
Multipurpose
Testpoint
5128 Keystone
