Texas Instruments UCD3138 User Manual

1.000%
6.000%
11.000%
0.1 0.3 0.5 0.7 0.9
Load Current (A)
115VAC 60Hz
230VAC 50Hz
www.ti.com Performance Data and Typical Characteristic Curves
9.3 Input Current at 115 V
AC
and 60 Hz
Figure 7. Input Current and Voltage 115 V
AC
and Half Load
Figure 8. Input Current and Voltage 115 V
AC
and Full Load
13
SLUU885B–March 2012–Revised July 2012 Digitally Controlled Single-Phase PFC Pre-Regulator
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated
