Texol Midgeater Max - Customer Assembly of Weather Cover

-
7
-
4. Customer Assembly of Weather Cover
REMOVE CUSTOMER PACK FROM GAS BOTTLE COMPARTMENT.
A POZI SCREWDRIVER IS REQUIRED FOR THIS ASSEMBLY:
Fig 1
Fig 2
Fig 3
THE PARTS YOU WILL HAVE ARE:
1 x HOOD
3 x STRUTS
12 x M4 SCREWS
SECURE THE 3 STRUTS TO THE
CHASSIS USING 6 SCREWS IN THE
ORIENTATION SHOWN IN Fig 2.
ATTACH THE HOOD TO THE STRUTS
USING 6 SCREWS IN THE
ORIENTATION SHOWN IN Fig 3.
