THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page P-16
SEATING
10015775 Service Parts Manual
1 *** Premium Seat Bottom Assembly (Includes Items 3 - 8)................................... 1
629269G2818 Mushroom
629269G2821 Premium Black
2 *** Premium Seat Bottom Assembly (Includes Items 4 - 9)................................... 1
629269G2518 Mushroom
629269G2521 Premium Black
3 *** Premium Seat Bottom Assembly ............................................................... 1
654085G18 Mushroom
654085G21 Premium Black
4 71610G01 Seat Hinge................................................................................................ 2
5 00720G08 Flat Head Phillips Screw, #12 -14 x 1" Lg................................................. 6
6 617645 Hip Restraint (Driver Side)........................................................................ 1
7 617644 Hip Restraint (Passenger Side) ................................................................ 1
8 615417 Button Head Torx Bolt, M10 - 1.5 x 25mm Lg............................................ 8
9 *** Premium Seat Bottom Assembly ............................................................... 1
693086G18 Mushroom
693086G21 Premium Black
10 *** Premium Seat Bottom Assembly...................................................................... 1
600082G18 Mushroom
600082G21 Premium Black
11 *** Premium Seat Back Assembly ......................................................................... 1
654084G18 Mushroom
654084G21 Premium Black
12 697694 Seat Back Tube Cap ........................................................................................ 1
To Next Page
