THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page R-4
10015775 Service Parts Manual
STARTER GENERATOR
1 699755 Starter/Generator Support Bracket .................................................................. 1
2 606235 Flanged Hex Head Bolt, M10 - 1.25 x 20mm Lg .............................................. 2
3
4
5 606261 Flanged Hex Head Bolt, M8 - 1.25 x 20mm Lg, Grade 8.8 .............................. 2
6
7 606256 Flanged Hex Head Bolt, M10 - 1.25 x 25mm Lg, Grade 8.8 ............................ 3
8 606255 Hex Jam Nut, M10 - 1.25 ................................................................................. 1
9 606274 Flanged Hex Nut, M10 - 1.25 ........................................................................... 1
10 630587 Starter/Generator Belt ...................................................................................... 1
11
12 12064G6 Push Nut, 5/16" ................................................................................................ 1
13 629763 Tensioner Bolt .................................................................................................. 1
To Next Page
