THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page S-2
10015775 Service Parts Manual
WEATHER PROTECTION
1 10012623G05 Sun Top Kit, 82" (Black) (Includes Items 5, 11 - 26)........................................ 1
2 10012623G04 Sun Top Kit, 82’ (White) (Includes Items 7, 11 - 26) ........................................ 1
3 10012623G06 Sun Top Kit, 82" (Tan) (Includes Items 9, 11 - 26)........................................... 1
4
5 607258 Sun Top, Black........................................................................................... 1
6
7 607580 Sun Top, White ......................................................................................... 1
8
9 643212 Sun Top, Tan............................................................................................. 1
10
11 10011801 Front Support............................................................................................. 1
12 617943 Rear Support (Driver Side) ....................................................................... 1
13 617942 Rear Support (Passenger Side) ............................................................... 1
14 10013156 Sun Top Hardware Kit (Includes Items 15 - 26) ........................................ 1
15 00665G5 Hex Head Bolt (SS), 3/8" - 16 x 1" Lg ................................................ 4
16 00679G1 Flat Washer (SS), 3/8" ....................................................................... 8
17 00771G5 Nylon Washer, 3/8"............................................................................. 4
18 00891G5 Lock Nut, 3/8" - 16 ............................................................................. 4
19 19853G1 End Cap, 1" Sq .................................................................................. 2
20 652311 Round Head Torx Bolt (Black), 5/16" - 18 x 3" Lg .............................. 4
21
22 634807 Spacer, .328" x .75" x .5".................................................................... 2
23 634808 Flat Washer, 5/16".............................................................................. 4
24 00441G2 Hex Head Bolt, 5/16" - 18 x 3 1/4" Lg ................................................ 6
25 00907G2 Flat Washer (SS), 5/16" ..................................................................... 12
26 11098G6 Lock Nut, 5/16" - 18 ........................................................................... 6
