THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page A-6
10015775 Service Parts Manual
ACCELERATOR
1 606005 Governor Bracket (Lower)................................................................................ 1
2 606284 Governor Link Rod ........................................................................................... 1
3 660005 Governor Rod Guard........................................................................................ 1
4
5 606083 Governor Bracket (Upper)................................................................................ 1
6 632936 Governor Cable / Direction Selector Bracket ................................................... 1
7
8 606283 Governor Lever Bushing .................................................................................. 1
9 606421 Flanged Hex Head Bolt, M6 - 1 x 30mm Lg, Grade 8.8 ................................... 1
10 606256 Flanged Hex Head Bolt, M10 - 1.25 x 25mm Lg, Grade 8.8 ............................ 2
11
12 606264 Flanged Hex Head Bolt, M6 - 1 x 20mm Lg, Grade 8.8 ................................... 1
13 73876G01 Flanged Hex Head Bolt, M6 - 1 x 12mm Lg, Grade 8.8................................... 1
14 601476 Lock Nut, M6 - 1............................................................................................... 1
15
16 450452 Flanged Hex Nut, M6 - 1 .................................................................................. 1
