Textron EZ-GO Express L6 User Manual

THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page B-2
10015775 Service Parts Manual
AIR FILTER
1 697026 Air Filter Assembly (Includes Items 2 - 12)....................................................... 1
2 688989 Air Cleaner Assembly (Includes Items 3 - 8) ............................................. 1
3 691746 Air Cleaner Cover................................................................................ 1
4 72604G01 Air Cleaner Clip ................................................................................... 2
5 28463G01 Air Filter............................................................................................... 1
6 28462G01 Dust Ejector Valve ............................................................................... 1
7 689987 Seal ..................................................................................................... 1
8 689988 Air Cleaner Housing ............................................................................ 1
9 11391G7 Hose Clamp, 1.56"..................................................................................... 1
10 659142 Air Cleaner Mounting Bracket.................................................................... 1
11 601910 Air Filter Tube ............................................................................................ 1
12 606261 Flanged Hex Head Bolt, M8 - 1.25 x 20mm Lg, Grade 8.8 ....................... 2
13 661661 Intake Extension Hose .................................................................................... 1
14 11391G5 Hose Clamp, .81" ............................................................................................ 1
15 11391G7 Hose Clamp, 1.56" .......................................................................................... 1
16 12416G2 Nylon Clamp, 11.8" Lg .................................................................................... 1
17
18 00414G7 Hex Head Bolt, 1/4" - 20 x 7/8" Lg, Grade 5 ................................................... 2
19 14390G4 Lock Nut, 1/4" - 20 .......................................................................................... 2
