THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page C-10
BODY
10015775 Service Parts Manual
1 625272G1** Rear Body (See HOW TO USE Section for COLOR CODES) ....................... 1
2 10570G10 Rivet (SS), 5/32" x 9/16" Lg ............................................................................. 5
3 10570G12 Rivet (Aluminum), .257" x .556" Lg .................................................................. 4
4 633917 Rivet (Plastic) ................................................................................................... 2
5
6 71320G01 Access Panel ................................................................................................... 1
7 01107G01 Pan Head Torx Screw (SS), #8 x .63" Lg ......................................................... 5
8
9 71609G01 Seat Hinge Plate .............................................................................................. 2
10 10570G11 Rivet (SS), 5/32" x .70" Lg ............................................................................... 4
11
12 71451G02 Rear Bumper.................................................................................................... 1
13
14 71102G01 Hex Head Bolt, 1/4" - 20 x 3/4" Lg, Grade 5 ................................................... 4
15 00571G2 Flat Washer, 5/16” ........................................................................................... 2
16 71455G01 Bumper Plug ................................................................................................... 4
17 71554G01 “J” Type Nut Retainer, 1/4” - 20........................................................................ 4
18 666066 Receptacle Cover............................................................................................. 1
19 71316G01 Hole Plug ......................................................................................................... 1
20
21 70244G05 Splash Pan....................................................................................................... 1
22 00715G2 Hex Washer Head Bolt, 5/16" - 18 x 4/5" Lg .................................................... 4
23 635054G04 Fender Liner (Driver Side)................................................................................ 1
24 635054G01 Fender Liner (Passenger Side)........................................................................ 1
25 16816G2 Ratchet Fastener, 1/4” x .887" ......................................................................... 4
To Next Page
