THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page D-2
10015775 Service Parts Manual
BRAKES
1 70690G02 Brake Pedal Assembly (Includes Items 2 - 30) ................................................ 1
2 652253G03 Park Brake Pedal....................................................................................... 1
3
4
5 70681G01 Torsion Spring............................................................................................ 2
6 70682G01 Pivot Pin .................................................................................................... 1
7 658825 Push Nut, 5/16” - 24 .................................................................................. 2
8
9 70257G01 Service Brake Pad..................................................................................... 1
10 16409G1 Oval Rivet, .375" x .468" Lg....................................................................... 6
11 70256G01 Park Brake Pedal Pad ............................................................................... 1
12 16409G1 Oval Rivet, .375" x .468" Lg....................................................................... 3
13 652820 Service Brake Pedal Plate......................................................................... 1
14 00737G8 Flat Head Phillips Screw, #10 - 24 x .875" Lg, Grade 5............................. 4
15 00739G1 Rubber Well Nut, #10 - 24 ......................................................................... 2
16 652355 Brake Pedal Spacer................................................................................... 2
17 27137G01 Conical Spring ........................................................................................... 2
18 14390G10 Lock Nut, #10 - 24 ..................................................................................... 2
19 10606G8 Micro Switch .............................................................................................. 1
20 00645G2 Pan Head Phillips Screw, #6 - 32 x 1 1/4" Lg ............................................ 1
21 00559G5 Flat Washer, #10........................................................................................ 2
22 00559G3 Flat Washer, #6.......................................................................................... 2
23 00565G3 Lock Washer, #6 ........................................................................................ 1
24 00525G5 Lock Nut, #6 - 32 ....................................................................................... 1
25 13514G1 Limit Switch Screw, #6 - 32 x .22" Lg ........................................................ 1
26 00642G8 Flat Washer, 5/16” ..................................................................................... 2
27 14628G1 Faston Tab................................................................................................. 1
28 24605G1 Wire Harness (Brake Light) ....................................................................... 1
29 17618G1 Wire Tie ..................................................................................................... 2
30 652791G03 Brake Pedal ............................................................................................... 1
To Next Page
