THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page D-4
10015775 Service Parts Manual
BRAKES
1 70582G01 Shoulder Bolt (SS), 3/8" - 16 x 3.406" Lg......................................................... 1
2 70581G01 Flanged Bushing, .1.062" O.D. x .795" I.D....................................................... 2
3 70676G01 Torsion Spring .................................................................................................. 1
4 00643G1 Lock Washer, 3/8" ............................................................................................ 1
5 11098G5 Lock Nut, 3/8" - 16 ........................................................................................... 1
6 01038G01 Hex Washer Head Bolt, 1/4" - 20 x .7" Lg (Not Illustrated)............................... 1
7 12416G2 Nylon Wedge Lock Clamp (Not Illustrated) ...................................................... 3
8
9
10
11 01111G01 Retaining Ring (SS), Dia. .8"............................................................................ 4
12 10386G3 Clevis Pin, .438" x .938" Lg.............................................................................. 1
13 10387G3 Cotter Pin, .094" x .75" Lg................................................................................ 1
14
15 70601G01 Kick-off Link...................................................................................................... 1
16 17838G1 Nylon Bushing, .37" O.D. x .31" I.D.................................................................. 2
17 20835G1 Teflon Washer, 3/8" .......................................................................................... 2
18 00559G8 Flat Washer, 5/16"............................................................................................ 2
19 10387G3 Cotter Pin, .094" x .75" Lg................................................................................ 2
20 70098G01 Kick-off Cam Pivot............................................................................................ 1
21 10097G6 Flanged Bearing............................................................................................... 2
22 70587G01 Kick-off Cam..................................................................................................... 1
23 71215G01 Set Screw with Patch Lock, 1/4" - 20 x 1/2" Lg ................................................ 2
24 14134G4 Spacer, .76" O.D. x .395" I.D. x 1.25" Lg ......................................................... 1
25 70113G01 Adjustable Bumper........................................................................................... 1
26 11027G1 Lock Nut, 5/16 - 18" ......................................................................................... 1
27 70080G02 Catch Bracket................................................................................................... 1
28 00414G6 Hex Head Bolt, 1/4" - 20 x 3/4" Lg, Grade 5 .................................................... 2
29 14390G4 Lock Nut (SS), 1/4" - 20 ................................................................................... 2
30 10386G3 Clevis Pin, .438" x .938" Lg.............................................................................. 1
31 10387G3 Cotter Pin, .094" x .75" Lg................................................................................ 1
To Next Page
