THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page E-2
10015775 Service Parts Manual
CLUTCH
1 672688 Primary Team Clutch (Includes Items 2 - 11) ................................................... 1
2 619333 Primary Starter Pulley................................................................................ 1
3 * Stationary Assembly .................................................................................. 1
4 * Moveable Primary Assembly ..................................................................... 1
5 624112 Shift Roller Assembly................................................................................. 6
6 619337 Shim, 39.5mm x 31.75mm......................................................................... 1
7 644303 Primary Spider Assembly .......................................................................... 1
8 * Primary Dust Cover Assembly................................................................... 1
9 644305 Torque Primary Button .............................................................................. 6
10 619332 Hex Washer Head Bolt, 1/4" - 20 x 3/4" Lg................................................ 7
11 644306 Torque Primary Plug ................................................................................. 6
12 623949 Secondary Team Clutch (Includes Items 13 - 19) ............................................ 1
13 * Secondary Stationary ................................................................................ 1
14 * Moveable Secondary................................................................................. 1
15 619327 Inner Retainer Spring ................................................................................ 1
16 624111 Compression Spring .................................................................................. 1
17 619329 Outer Spring Retainer................................................................................ 1
18 652515 External Retainer Ring .............................................................................. 1
19 619331 Thrust Washer, 1 53" x 1 83" x 1" .............................................................. 1
20
21 606239 Conical Washer, M12 ....................................................................................... 2
22 00566G3 Lock Washer (Spring Type), 3/8" ..................................................................... 2
23 606245 Hex Head Bolt, M12 - 1.25 x 160mm Lg, Grade 8.8 ........................................ 1
24 606243 Hex Head Bolt, M12 - 1.25 x 120mm Lg, Grade 8.8 ........................................ 1
25 606230 Clutch Washer, 27.5 Dia. O.D. x 13.06 Dia. I.D. .............................................. 1
26 618630 Drive Belt.......................................................................................................... 1
To Next Page
