Textron EZ-GO Express L6 - Page 53

THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page G-2
10015775 Service Parts Manual
ELECTRICAL
1 607053 #6 GA Wire (Black 6", F1 - A2)........................................................................ 1
2 25682G01 Terminal Cover ................................................................................................ 1
3 25682G01 Terminal Cover (For CE Certified Vehicles) .................................................... 2
4
5 637484 Battery, 12V, HD.............................................................................................. 1
6 640488 Battery Bolt ..................................................................................................... 2
7
8
9
10 72101G02 Battery Hold Down .......................................................................................... 1
11 00438G6 Hex Head Bolt, 5/16" - 18 x 3/4" Lg, Grade 5 ................................................. 1
12 00565G8 Lock Washer, 5/16" ......................................................................................... 1
13 00571G2 Flat Washer (SS), 5/16" .................................................................................. 1
14 652441G03 Battery Tray..................................................................................................... 1
15 00715G2 Hex Washer Head Bolt, 5/16" - 18 x .8" Lg ..................................................... 4
16 645191 Battery/Engine Ground Cable ......................................................................... 1
17
18 00438G6 Hex Head Bolt, 5/16" - 18 x 3/4" Lg, Grade 5 ................................................. 2
19 11027G1 Flanged Lock Nut, 5/16" - 18 .......................................................................... 2
20 26676G01 Flanged Hex Head Bolt, M6 - 1 x 23mm Lg .................................................... 1
21 606264 Flanged Hex Head Bolt, M6 - 1 x 20mm Lg, Grade 8.8 .................................. 1
22
23 607103 #6 GA Wire, 42" Lg ......................................................................................... 1
24 10011587 Main Harness.................................................................................................. 1
25
26 73049G01 Direction Selector Cover ................................................................................. 1
27 16469G1 Fender Washer, 1/4" ....................................................................................... 1
28 00114G6 Hex Washer Head Slotted Tapping Screw, 1/4" - 14 x 3/4" LG ....................... 1
29 608772 #6AWG Wire (Blue) (For CE Certified Vehicles) (Not Illustrated) ................... 1
30 625757 #6AWG Wire (Blue) (Solenoid - F2) (For CE Certified Vehicles) (Not Illustrated) 1
