THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page G-4
10015775 Service Parts Manual
ELECTRICAL
1 660446 Electrical Plate Assembly (Includes Items 2 - 11) ........................................... 1
2 73057G02 Bracket ..................................................................................................... 1
3 27739G01 Voltage Regulator ..................................................................................... 1
4 663716 Solenoid.................................................................................................... 1
5 303459 Hex Head Bolt, 1/4" - 20 x 1 1/2" Lg, Grade 5 .......................................... 1
6 00661G8 Hex Head Bolt (SS), 1/4" - 20 x 1" Lg....................................................... 1
7 11027G2 Flanged Lock Nut, 1/4" - 20 ...................................................................... 2
8 658683 Electrical Plate Harness ........................................................................... 1
9 73446G01 Faston Tab, 90º......................................................................................... 2
10 645190 #6 GA Wire Assembly............................................................................... 1
11 25978G56 #18 GA Wire Assembly (Black)................................................................. 1
12 00567G7 Lock Washer (External Tooth Type) ................................................................. 1
13 00532G1 Hex Nut, 1/4" - 20............................................................................................ 1
14
15 15058G6 Aluminum Rivet (Black) (Not Illustrated) ......................................................... 2
(To Fix Main Harness on Fender Liner)
16
Items 17 - 22 Not Shown
17 603282 Relay, 1C, 40A, 12V........................................................................................ 1
18 663593 Micro Relay, 12V ............................................................................................. 1
19 636455G12 Mini Fuse, 10A, 32V........................................................................................ 1
20 636455G13 Mini Fuse, 15A, 32V........................................................................................ 1
21 636455G10 Mini Fuse, 5A, 32V.......................................................................................... 1
22 636455G14 Mini Fuse, 20A, 32V........................................................................................ 1
To Next Page
