THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page K-4
10015775 Service Parts Manual
FRONT SUSPENSION AND STEERING
1 70964G01 Steering Box Assembly (Includes Items 2 - 23) ............................................... 1
2 70965G01 Steering Rack Cover and Bearing ............................................................. 1
3
4 * Jam Nut, 1/2" - 20...................................................................................... 1
5 70750G01 Retaining Ring (External) .......................................................................... 1
6 15112G1 Ball Bearing, O.D 1.65" x I.D .78".............................................................. 1
7 70603G01 Pinion......................................................................................................... 1
8 70751G01 Retaining Ring (Internal)............................................................................ 1
9 70638G01 Seal (Pinion) .............................................................................................. 1
10 70604G01 Steering Rack ............................................................................................ 1
11 * Set Screw, #10 - 32 x .25" Lg .................................................................... 1
12 70590G01 Rack Loader .............................................................................................. 1
13 70666G01 Compression Spring .................................................................................. 1
14 70645G01 Gasket (Rack Loader Cover)..................................................................... 1
15 652259 Cover (Rack Loader) ................................................................................. 1
16 71102G01 Hex Washer Head Bolt, 1/4" - 20 x 11/16" Lg, Grade 5............................. 2
17 10389G3 Grease Fitting (Straight) ............................................................................ 1
18 70694G01 Rod End (Inner) ......................................................................................... 1
19 70961G01 Rack Boot .................................................................................................. 1
20 12416G2 Nylon Clamp, 10" Lg.................................................................................. 1
21 11391G8 Hose Clamp, 1.81"..................................................................................... 1
22
23 70695G01 Tie Rod End (Outer) (Includes Items 24 - 25)............................................ 1
24 50641G1 Grommet ............................................................................................. 1
25 50209G02 Hex Slotted Nut, 7/16" - 20 ................................................................. 1
26 10387G2 Cotter Pin, 3/32" x 1"........................................................................................ 1
To Next Page
