THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page K-6
10015775 Service Parts Manual
FRONT SUSPENSION AND STEERING
1 00464G6 Hex Head Bolt, 7/16" - 14 x 2 3/4" Lg, Grade 5 ............................................... 2
2 01068G01 Hex Head Bolt, 7/16" - 14 x 3.5" Lg, Grade 5 .................................................. 1
3 70667G02 Spacer, O.D, 1" X I.D .46" x 1.2" Lg ................................................................ 2
4 70667G04 Spacer, O.D 1" X I.D .46" x .69" Lg .................................................................. 1
5 00463G11 Hex Head Bolt, 7/16" - 14 x 1 1/2" Lg, Grade 5 ............................................... 2
6 00560G2 Flat Washer, 7/16"............................................................................................ 7
7 00734G1 Lock Nut, 7/16" - 14 ......................................................................................... 3
8 00532G7 Hex Nut, 1/4" - 20............................................................................................. 1
9 01006G01 Hex Washer Head Bolt, 3/8" - 16 x 1 1/4" Lg ................................................... 4
10 00879G1 Lock Washer, 3/8" ............................................................................................ 4
11
12 70758G05 Steering Column Assembly (Includes Items 13 - 25) ....................................... 1
13 70610G03 Steering Column........................................................................................ 1
14 28569G01 Steering Column Bushing.......................................................................... 1
15 10026871 Pan Head Torx Screw, #6 - 20 x .25" Lg.................................................... 1
16 70607G01 Steering Shaft............................................................................................ 1
17 15112G1 Ball Bearing, O.D 1.65" x I.D .78".............................................................. 1
18 70887G01 Wave Washer ............................................................................................ 1
19
20 70580G01 Intermediate Shaft ..................................................................................... 1
21 01055G01 Hex Head Bolt, M8 - 1.25 x 1.18" Lg, Grade 5 .......................................... 1
22 00565G8 Lock Washer, 5/16".................................................................................... 1
23
24 70751G01 Retaining Ring (Internal)............................................................................ 1
25 70888G01 Retaining Ring (External) .......................................................................... 1
26 10012163 Steering Wheel Adapter ................................................................................... 1
27 10013920 Steering Wheel (Premium)............................................................................... 1
28 0405-620 Center Cap (Steering Wheel)........................................................................... 1
29 14390G2 Lock Nut, 5/8" - 18 ........................................................................................... 1
30 01055G01 Hex Head Bolt, M8 - 1.25 x 1.18" Lg, Grade 5................................................. 1
31 00565G8 Lock Washer, 5/16" .......................................................................................... 1
To Next Page
