THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page L-2
10015775 Service Parts Manual
FUEL SYSTEM
1 646825 Fuel Tank Assembly (with Sender Unit) (Includes Items 2 - 8)......................... 1
2 646306 Fuel Tank ................................................................................................... 1
3 646837 Fuel Pump Retaining Ring......................................................................... 1
4 646838 Seal ........................................................................................................... 1
5 647810 Grommet.................................................................................................... 1
6 647809 Rollover Valve............................................................................................ 1
7 670898 Fuel Cap .................................................................................................... 1
8 646353 Fuel Pump with Sender Assembly............................................................. 1
9 32372G6 Vinyl Trim, 6.25" Lg .......................................................................................... 1
10 666351 Fuel Hose Assembly ........................................................................................ 1
11
12 664747 Tube Clamp, .5" ............................................................................................... 2
13
14 606264 Flanged Hex Head Bolt, M6 - 1 x 20mm Lg, Grade 8.8 ................................... 2
15 70483G01 Spacer, 5/16" - 18 ............................................................................................ 1
16 00438G8 Hex Head Bolt, 5/16" - 18 x 1" Lg, Grade 5 ..................................................... 1
17 11098G6 Lock Nut, 5/16" - 18 ......................................................................................... 3
18 00559G8 Flat Washer, 5/16"............................................................................................ 4
19 10570G11 Domed Rivet, 3/16" .......................................................................................... 2
20 606310 Carbon Canister Mounting Bracket .................................................................. 1
21 662807 Carbon Canister Assembly (Includes Items 22 - 26) ....................................... 1
22 10006822 Carbon Canister ........................................................................................ 1
23 18292G1 Tube Clamp, 1/2" O.D ............................................................................... 2
24 606963 Tube Clamp, 3/16" I.D ............................................................................... 2
25 27184G14 Fuel System Tube, 13" Lg ......................................................................... 1
26 662608 Hose, 3/16" I.D. x 37" Lg ........................................................................... 1
To Next Page
