GB-15
JACOBSEN G PLEX II Series: ZV
MAINTENANCE AND PARTS MANUAL
GB
NOTICE
• DO NOT overfill. Engine overheating and
damage may result.
1
Figure 31
1. Dipstick (diesel engine)
1
Figure 32
1. Oil Filler Port (diesel engine)
DO NOT use a wrench when installing the filter, use
hand pressure ONLY.
ENGINE OIL FILTER
When replacing the oil filter, apply a light film of
clean oil to the rubber seal. screw filter on until the
seal contacts the crankcase, then tighten 1/2 turn
more.
oil filter (diesel) PN 840160
