7 LINE IN
1/4" phone input sockets for line signals.
8 LINE OUT
1/4" phone output sockets for line signals.
9 AUX
1/4" phone input sockets for AUX signals.
10 LINE/MIC
Push button to select the input sensitivity of the device (line or microphone level).
11 OUTPUT
NL4 mounting connector (1+/1–) to connect another passive speaker.
Connections and operating elements
active full-range speaker
16
