12 STANDBY
Push button to enable or disable the energy saving mode.
When the box receives no signal for 60 minutes, it switches to standby mode. When it receives a signal again, it auto‐
matically switches back to normal mode.
LED ACTIVE
Power indicator LED. This LED is permanently on in normal mode. It goes off when the energy-saving mode is ena‐
bled and the box enters the standby mode.
LED STANDBY
Standby mode. This LED lights up when the energy saving mode is enabled and the box enters the standby mode. It
goes off again when the box switches back to normal.
13 ON / OFF
Mains power switch to turn the device on or off.
14 IEC chassis connector with fuse holder for operating voltage supply.
Connections and operating elements
RA8
17
